优诺威非接触式扫描仪

UNIONOVO PN1 is a new A2+ professional book scanner. It is suitable for A2+ books, drawings, magazines and scrolls.

It is the first choice for professional occasions including ancient book protection and industrial drawing scan. It applies the overhead and single scanning system design. It is equipped with an automatic book bracket which is able to adjust the height of books and it avoids bending the book spines.Luminescent LED with no ultraviolet ray or infrared ray will not cause radiation damage.

It has touch button and it can achieve high-speed scanning; the scanning speed can reach 3 seconds per page or 3 seconds for 2 pages; this speed is leading the industry.

Less cost, less waste, high-tech environment-friendly product

High price performance ratio; save budget

Portable design, easy to install

Maximum protection of books:

Overhead design, no need to tear the books apart

No need to put the files or books upside down; only need to put the materials on the book bracket

Bracket can automatically adjust the left and right height book pages, do not worry about the book spine bending

Luminescent LED with even lights; light intensity is over 600 LUX; CRI≥80; no ultraviolet ray; able to protect the rare books to the largest extent

Top scanning quality & extremely high OCR recognition accuracy

Generate XML metadata which is convenient for filing and searching books

Fast scanning; 3 seconds/page or 3 seconds/2 page

Automatic capture boundary,Automatic deskew

Able to output 100-600 DPI color, gray level or black and white images

Max. scanning size: 650x460mm; Max. thickness: 130 mm

ICC image correction which can improve image quality

Support single page, multiple page, PDF, JPG, JPG 2000, TIFF, BMP, RAW and other formats of output

Powerful file management function; easy to insert, replace and delete without worrying about file name issue

Automatic book bracket can automatically adjust the height of the books on the left and the right sides; no need to worry about bending the book spines

Automatic page capture & tilt correction

Diverse accessories available, such as the automatic scanner, laser focuser, software time switch, USB foot switch USB keyboard etc.; convenient and fast

Real-time scanning direction adjustment; suitable for books with different printing directions

Camera parameters can be easily set in order to achieve the best performance

Support bar code scanning, facilitating the establishment of books database

More camera support, such as Nikon,Phase One,Hasselblad camera , to meet different

budget

Free region selection can greatly shorten the time of post processing

Automatic focusing based on the preset time; always keep the images clear

Automatic exposure control & color correction

Patented design; good appearance

Real-time preview function; can be used as a 3D object display platform

Provide software remote assistance; no further trouble

Ergonomics design is suitable for long-time operation

Simple maintenance; easy operation

Video
Parameters
ABUIABAEGAAgv7bdiQYo6o7uiwcwXjiGAQ

Project

Parameter

Scan Speed

3 seconds / page (two pages)

Chip

53 MP scanning system

24.2 MP scanning system

Camera configuration

Single camera

Resolution

100-600Dpi, color, gray, black and white image

Media Size

650x460mm ,Max. thickness 130mm

Lighting system(Optional)

no ultraviolet ray or infrared ray

luminescent LED

light intensity is over 600 LUX

color rendering index80

(up to IEC60825-1 International safety standard)

Product Dimension

66(120Including Lamp)x 65 x 110CM (W x D x H)

Packing Size

75x 75 x 50 CM (W x D x H)

Product Weight

43KG

Packing Weight

56KG

Output

JPG,TIFF,PDF,RAW ,DjUv,and PDF/A

Opac input

ISBN, ISSN, signature, bar code

Communication

USB 2.0/3.0

Certification

CE,3C

Power

Standard 110-240 VAC, 50/60 Hz 15 Amp socket

OS

Windows 7,XP(Sp3)

System
requirement

CPU 3.2 GHz or higher

RAM 8 GB minimum

500 GB available disk space

1024 x 768 resolution monitor

Basic Package

UNIONOVO PN I scanner
UNIONOVO Capture software

UNIONOVO Editor software

Flat transparent draft pressure device

Adjustable base

Luminescent LED

USB Auto Capture Switch

USB HUB

AC power adapter x1

USB HUB

Anti-dazzle shelter

USB foot switch

Optional

53 MP scanning systemx1 or 24.2 MP scanning system 1

Plastic Color Test Card

Barcode scanner

AC Adaptersx1

ABBYY OCR software

Warranty

12Months

Download
300dpi.rar
6.71MBDownload
600dpi.rar
18.11MBDownload
800dp-1.rar
41.72MBDownload
800dpi-2.rar
37.13MBDownload
brochure PN1.pdf
466.31KBDownload
Planetary Scanner PN1
